50 LPH RO Water Plant

50 LPH RO Water Treatment Plant

50 Litres per Hour RO Water Plant is widely used for small offices, Schools, Colleges, Hospitals, Retail Stores, Hotels, Restaurants, etc.,

Purification Method

Reverse Osmosis

Purification Stages

6 Stage Purification

Purification Capacity

50 LPH (Litres per Hour)

Maximum Duty Cycle

500 Litres per Day

Purification Stages:

The whole purification is carried out in 6 stages that includes Pre-Filtration, Pre Carbon & Post Carbon Filtration, Micron Filtration (up to 5 Microns), Reverse Osmosis (RO) Filtration, UV Filtration.

Stage 1: Micron Filter (Removes contaminants up to 5 Microns)

Stage 2: Active Carbon Filter (Removes color and odor)

Stage 3: Spun Filter

Stage 4: RO Membrane Filtration (Removes contaminants above 0.0001 microns)

Stage 5: Post Carbon Filter

Stage 6: UV Filtration (to kill bacteria & viruses present in the purified water)

Components Included:

 A total of 18 components are included in the whole system.

The following are the components required for 50 Litres per Hour RO Water Treatment System.

  • RO Membranes: 4 No.s
  • Booster Pumps: 2 No.s
  • Membrane Housings: 4 No.s
  • Wound Filter (5 Microns): 1 No.
  • Spun Filter: 1 No.
  • Micron Filter Housings: 2 No.s
  • Carbon Filter Housing: 1 No.
  • Post Carbon Filter Housing: 1 No.
  • SMPS/ Adapter: 1 No.
  • Stainless Steel Frame: 1 No.
